• Engine accessories:
  • Heavy-duty air filter
  • Coolant heater
  • Lube oil heater
  • Fuel and Water Separator
• Cooling system
  • 50˚C radiator
  • Heat exchanger + water cooling tower + External water circulation pumping system + Remote horizontal water tank system
• Control System: Other Deep Sea Controls Inc
• Circuit Breaker: ABB 2, 3 and 4 pole thermo-magnetic
• Automatic Transfer Switch: ATS- available in Nema 1 and 3R, 2 and 3 pole
• Optional Fuel Tank: UL142 listed double wall tank available in 8, 12, and 24 hour sizes

• Model: DEUTZ TD2.9
• Aspiration: Turbocharged
• Type: In line
• No. of Cylinders: 4-4 Cycle
• Governor Type: Isochronous Governor ECM controlled
• Engine power: 57 kW
• Displacement: 2.9 L
• Bore×Stroke: 3.62x4.33 in
• Compression Ratio: 18.2:1
• Rated Speed: 1800 RPM

• Prime Power Fuel Consumption @ 100%: 3.1 IGPH
• Fuel: Diesel #2
• Standby Power Fuel Consumption @ 75%: 2.5 - GPH
• Injection System: Highpressure common rail

• Oil Capacity: 3.4 G
• Lube #: API-CF 15w40

• Coolant Capacity: 4.1 G
• Thermostat range: 85-95 ˚C
• Max Top Tank Temp: 112 ˚C
• Fan air flow: 154m3/m
• Fan Drive Type: Shaft Drive

• Air intake capacity: 8.4 m3/m3
• Air Pressure: ≦ 3 KPA

• Exhaust Gas Flow: 22.1 m3/min
• Max Back Pressure: 10.2 kPa
• Exhaust gas temp: 480
• Outlet size: 72mm-3"

• Start Mode: Electric start
• Battery: 120 Ah

• Alternator Model: MECC ALTE ECP32
• PF: 0.8
• Phase: 3
• Connection: 3P 4W，Y connection
• Winding Pitch: 2/3
• Insulation Class: H/H
• Tel. Influence: TIF: <50 THF: >
• Harmonic: 2%
• Coefficient Voltage: ≥±5%
• Adjust Scope

• Rate Power: 53/66.5 kW/kVA
• Voltage: 208/120 V
• Frequency: 60 Hz
• Bearing: Single Bearing
• Protection Class: IP21
• Efficiency: 85.80%
• Voltage: ±1.0%
• Regulation AVR: SR7-2G
• Excitation: Self-excited

Electronic J1939 (CAN) and Modbus capable. MPU and alternator sensing engine support for diesel, and gas engines all in one controller. With a large number of flexible inputs, outputs and protection circuits. The modules can be easily adapted to suit a wide range of applications.

• Utility voltage sensing
• Generator/load power monitoring - (kW, kVA, kVAR, pf)
• Generator overload protection (kW)
• Efficient power save mode
• Mains and generator closed via front panel
• 4 Configurable DC outputs
• 4 Configurable analog/digital inputs & stopping
• 6 Configurable digital inputs
• Support for 0-10 V & 4-20 mA oil pressure sensors
• Configurable staged loading
• CAN, MPU and alternator speed sensing in one variant
• 3 Engine maintenance
• Engine speed protection

• Engine pre-heat
• Multiple date and time scheduler
• Engine idle control for starting
• Fuel pump control
• Battery voltage monitoring
• Start on low battery voltage output
• Configurable remote start input
• Alternative configuration
• Alarm including common alarm, common electric and common shutdown
• LCD and LED alarm indication
• Configurable event log (50)
• Heated display option available

For more information, please visit the Dyna Gen Controls website

1. Standard warranty for Three years or 3000 hours (whichever comes first) from initialsales date to the end user. Refer to Intech Equipment Power Diesel Generator WarrantyManual for more details.

2. Maintenance parts (filters, belts, hoses, batteries), improper operation andmaintenance failures are excluded from the warranty policy.

• Open Unit Size (LXWXH)
• Enclosed unit (LXWXH)
• Weight Open unit
• Weight Enclosed unit 69.05 x 25.78 x 42.59 in
• 90.55 x 43.30 x 45.66 in
• 608kg (1340lbs)
• 1400kg (3086lbs)
